Shore Durometer HPSD

Durometer according to Shore for determining the indentation hardness of hard rubber, rigid thermoplast, resopal, hard plastic materials

Shore D hardness tester according DIN 53505, ISO 48-4, ISO 868 and ASTM D 2240

Durometer with large seating for accurate measuring

Categories: HPS Series, Shore Durometer

Print page

Special Features

The spring loaded outer ring assures a constant measuring pressure and eliminates false readings due to difference between operators.

Flat bottom prevent tilting and improves the measuring accuracy.

Shore hardness tester with 18 mm Working face diameter

Adjustable Min./Max. indicator marks to highlight the working range of the durometer HPSD

Optionally available: Calibration certificate with calibration report

Standard Features

Easy to use

High repeatability

Durometer with an application range of 10 – 90 Shore D units

Certificate of Compliance with the order 2.1 according EN 10204 is included

Available Models

Model	Shore	Application
HPSD	Shore D	hard rubber, rigid thermoplast, resopal and hard plastic materials
		alternative
HPSA	Shore A	soft rubber, elastomers, natural rubber, soft PVC, leather, etc.	more
HPSA-R-M	Shore A	rubber coated rollers, rollers, and cots	more
HPSB	Shore B	for harder material than Shore A	more
HPSC	Shore C	medium hard rubber, elastomers and plastic	more
HPSDO	Shore DO	plastic and medium hard to hard rubber materials	more
HPSO	Shore O	soft elastomers, soft elastic materials, medium fast textiles	more
HPSAO	Shore AO	foams, steering wheels and inner linings of motor vehicles	more

Indentor

Cone	Tapered pin	U-grooved	Ball
Shore A Shore C	Shore B Shore D	Shore O Shore DO	Shore AO

Specifications

Indentor:	Tapered pin 30°, 1.25 mm Ø
Depth of indentation:	0 – 2.5 mm
Typical applications:	Hard rubber, rigid thermoplast, resopal, hard plastic materials
Accuracy:	± 1 hardness unit
Application range:	10 – 90 Shore D
Standard:	DIN 53505, ISO 48-4, ISO 868, ASTM D 2240
Measuring spring force:	…4.45 – 44.5 N
*Test pressure:**	Approx. 50 N
Display range:	0 – 100 Shore D units
Scale diameter:	54 mm
Working face:	18 mm Ø
Base plate:	45 mm Ø
Weight, net (gross):	Approx. 300 g (500 g)
Dimensions:	50 x 58 x 114 mm (LxWxH)

Specifications subject to change without notice!

* Spring load of outer ring to create constant pressure

Operation

For measuring the hardness, the spring-loaded outer ring of the housing is pressed downwards until the edge of the ring meets the colored marking on the housing. This ensures a constant pressure and prevents measuring errors.

General:
The principle used to measure shore hardness is based on measuring the resistance force of the penetration of a pin into the test material under a known spring load. The amount of penetration is converted to hardness reading on a scale with 100 shore units.
As the depth of indentation is max. 2.5 mm the test material has to have a minimum thickness of 6 mm. If thickness is less stack some samples till you reach the required thickness.

Operation with a shore durometer of HPS series

Attachments and Accessories

Code M - Memory pointer
Memory pointer to capture and store value (last or highest reading) during measuring.
Order code: HPSD-M

PSHP - Test Stand
Model PSHP for series measurements
– Spring loaded lever for fast, precise positioning
– Height adjustable 0 – 200 mm
– Stroke lever action 40 mm
– Dimensions 162 x 100 x 320 mm (LxBxH)
– Weight net: approx. 2,3 kg
Various plates are optional available,
ask for more information !

HP-P20-100 - Control Rings for 20, 40, 60 and 80 Shore
To determine the displacement at 20, 40, 60 and 80 Shore.
Includes a base disk as basis for the control rings and an inspection certificate.
Order number: HP-P20-100
